Passer for på følgende biler :
2020-2023 Corvette
2008-2019 CTS - XTS
| bs Tone Ring Included | No |
| Bolt Circle Diameter (IN) | 4.724 |
| Bolt Circle Diameter (MM) | 120 |
| Center Bore Diameter (IN) | 2.7in |
| Center Bore Diameter (MM) | 68.6mm |
| Center Hole Diameter (IN) | 4.724 |
| Center Hole Diameter (MM) | 120 |
| Construction | Full Cast |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Disc Finish | Directional |
| Discard Thickness (IN) | 1.063 |
| Discard Thickness (MM) | 27 |
| Hat Finish | Plain |
| Height (IN) | 2 |
| Height (MM) | 50.8 |
| Inside Diameter (IN) | 8.425 |
| Inside Diameter (MM) | 214 |
| Length (IN) | 14.1 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter (IN) | 2.654 |
| Mounting Bolt Hole Circle Diameter (MM) | 67.4 |
| Mounting Bolt Hole Diameter (IN) | 2.654 |
| Mounting Bolt Hole Diameter (MM) | 67.4 |
| Nominal Thickness (IN) | 1.181 |
| Nominal Thickness (MM) | 30 |
| Outside Diameter (IN) | 13.583 |
| Outside Diameter (MM) | 345 |
| Overall Height (IN) | 2.008 |
| Overall Height (MM) | 51 |
| Rust Resistant Coating | No |
| Slotted | No |
| Solid Or Vented Type Rotor | Vented |
| Surface Type | Smooth |
| Weight (lb) | 25.5 |
| Width (IN) | 14.1 |
Hvis du er i tvivl om det er den rigtige reservedel til din Amerikaner bil, så endelig ring eller email til os.
